Downloads
Feel free to download the files listed below to experience the quality of our work and to see examples of the models, files and reports that we can deliver.
To access the files, click the download button.
Included Files
Fender
Christmas Ornament STL
Using our Breuckmann white light 3D scanner, a high level of detail was captured on the this Christmas Tree Ornament.
Airfoil
Approximately 3” in height, this small airfoil from a jet engine was scanned using our Breuckmann smartSCAN 1.4 megapixel camera.
- STL File
- IGES File
- STEP File
- PRT File (Wildfire 4.0 Pro/E parametric model)
- SLDPRT File (SolidWorks non-parametric model)
Clamp
Metal stamping roughly 1’’ square. Clamp was scanned with our Breuckmann whitelight system. Provided examples are “as-is” NURBS models.
Gear
Injection molded Gear that was scanned with our Breuckmann whitelight system. Provided examples are “as-is” NURBS models.
- IGS File (solid model)
- IGS File (surface model)
- STEP File (solid model)
- STEP File (surface model)
- 3D enabled PDF download (solid model)
- 3D enabled PDF download (surface model)
1911
This gun example is to show the photo overlay capabilities using our laser based systems.
Large Ant
This was scanned with Breuckmann technology. It was a small field of of view for high detail resolution.
Bee
Using a small FOV on our Breuckmann whitelight a high level of detail was captured on the bee.
Quarter
A US quarter was scanned using our Breuckmann white light system. Download the IGES or STL file to see the incredible resolution and detail capable using this technology.
Bullet
This is an inspection report completed with PolyWorks IMInspect. Download the PDF to view an example of our CAD to point cloud inspection and report.
